STE18-d adopts 35 mm DIN rail mounting and rod mounting accessories, which is composed of two parts. Customer interface unit (CIU) and metering control unit (MCU). The CIU is a keyboard based display installed anywhere in a consumer's home with a plug. MCU is the main instrument, which is installed in the information kiosk, instrument box far away from the consumer's home or the shell installed on the pole. MCU communicates with CIU through PLC, RF, Lora or 2 wireless communication. This off-line setting allows utilities and service providers to easily check at any time without having to visit the consumer's house, and reduces the chance of tampering fraud.
The meter can also be integrated with African local mobile money for prepayment, like M-pesa, MTN, Airtel through API(Application Programming Interface), which is the agreement connecting the third party APP and our Stronpay vending software. In this way, users can top up electricity credit by mobile money without leaving the house and could check information by their telephone at hand with internet accessibility.
Basic Functionality
Function Details
Prepayment STS Standard, recharge by input 20digits TOKEN, Trip on no credit or preset balance level
Low credit alarm Alarm value can be set by inputting corresponding TOKEN
Prepaid and post-paid switch Meter can be switch to prepaid mode or post-paid mode
Load control function Meter can be programmed for load control threshold, If the current power is more than threshold. The meter will cut off user load.
Event recording Meter can record the tamper event, open cover event, purchaseevent and TOKENS.
Self-testing Meter has a self-test function, it can test LCD and relay etc. and report the results directly
Anti-fraud features Meter will automatically close the valve after detection of magnetic field and open cover event
TOU Tariff TOU Tariff can be set by inputting corresponding TOKEN
Overdraft Collection Electricity Overdraft can be collected day by day or month by month
Communication The meter is available with AMI system through LORARF or PLC on request
Information Inquiry Consumer could check the data like Credit Remain, Total Purchased and Total Credit by input the short code
| Nominal Voltage | 230V |
| Working Voltage Range | 70%~120%Un |
| Nominal Frequency | 50-60Hz |
| Basic Current (Ib) | 5A |
| Maximum Current (Imax) | 80A |
| Starting Current (Ist) | 20mA |
| Active Energy Constant | 1000imp/kWh |
| Measurement Accuracy | Class 1.0 |
| Power Consumption in Voltage Circuit | <2W <8VA |
| Power Consumption in Current Circuit | <1VA |
| Operation Temperature Range | -25℃-70℃ |
| Storage Temperature Range | -40℃-85℃ |
Electric Magnetic Compatibility
| AC Insulation Strength | 4kV at 50Hz during 1min |
| Impulse voltage 1.2/50 us mains connections | 8kV |
| Electrostatic Discharges | Contact discharge | 8kV |
| Air discharge | 16kV |
| Electromagnetic RF Field | 27MHz-500MHz | 10V/m |
| 100KHz-1GHz | 30V/m |
| Fast transient burst test | 4kV |
| Protection | Class II |
